Emerson EPRO PR6424/001-000 16mm Eddy Current Sensor without armor, 4 meters calbe length
Description:
PR6424/001-000 is Emerson 16mm Eddy Current Sensor.
PR6424/001-000 is M18x1.5 sleeve thread, without armored cable, 50mm sensor length, adapotor plug, 4 meter total cable length with Lemo CON cable end.
As a 16mm Eddy Current Sensor, PR6424/001-000 is non-contact sensor designed for critical turbomachinery applications such as steam, gas and hydro turbines, compressors, pumps and fans to measure radial and axial shaft dynamic displacement; position, eccentricity and speed/key.

Specifications
Tip Diameter: 16.0 mm
Measurement range: ±2.0 mm Position, 100 to 1000 μm PP Vibration
Frequency Range: 0 to 20 kHz
Sensitivity: 4 V/mm (101.6 mV/mil) ±1.5%
Sensor Body Thread: M18x1.5
Temperature Range: -35 to 150°C (-31 to 302°F)
Temperature Error: <4%/100°K (API 670 Compliant)
Pressure Resistance to Sensor Head: 10,000 hPa (145 psi)
Agency Rating: CE, CSA, ATEX (see converter spec sheet)

Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheets
