ABB DA701F 3BDH000371R0001 mix of analog and digital I/O module

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this zoey@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheet

• 3BDH000371R0001

• ABB Type Designation:DA 701F

• Catalog Description:DA 701F is a mix of analog and digital I/O module. It provides 16 digital inputs, 8 digital outputs, four analog inputs and two analog outputs.

• Long Description:The analog input/output module DA 701F offers quite more flexibility, as it combines analog input and output as well as digital input and output channels in one module with 30 channels.
  Four of these channels can be individually configured as analog inputs, which can again sense voltage, current, or temperatures (RTD). Two channels can be configured as analog voltage outputs (-10 V to +10 V), or analog current outputs (0 … 20 mA or 4 … 20 mA). 16 channels are digital inputs (24 V DC) and the remaining 8 channels are usable for digital output signals (24 V DC).
  The inputs and outputs are electrically isolated from the other electronic circuitry of the module. There is no potential separation between the channels.
  This module is usable for PROFIBUS remote I/O and AC 700F / AC 900F direct I/O
