ABB AI723F 3BDH000376R0001 Analog Input Module

NEW AND ORIGIN ITEM IN STOCK

WITH ONE YEAR WARRANTY

Hope anyone enquire from us,pls click this zoey@nseauto.com
1. lower your support costs
2, Provide on-going availability of automation replacement parts
Quantity available: 1
Warranty: 12 months.
Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
Technical specification, manuals and data sheet

The analog input module AI 723F comes with 16 input channels in two groups.
Each of these channels can be individually configured depending on its intended usage.
Possible applications are sensing a voltage (0…10 V or -10…+10 V), sensing a current (0…20 mA or 4…20 mA) or temperature measurement (platinum or nickel resistance thermometers Pt100, Pt1000, Ni1000) in two- or three-wire configuration. Configuring the inputs as digital inputs is also possible. The inputs are electrically isolated from the other electronic circuitry of the module. There is no potential separation between the channels.
This module is usable for PROFIBUS remote I/O and AC 700F / AC 900F direct I/O
