330703-000-040-10-02-05 Bently Nevada 3300 XL 11 mm Proximity Probes

Bently Nevada 3300 XL 11 mm Proximity Probes 330703-000-040-10-02-05

Brand:
Bently Nevada TSI
Item NO.:
330703-000-040-10-02-05
Order(MOQ):
1 PC
Payment:
T/T
Product Origin:
USA
Shipping Port:
Xiamen
Lead Time：
In stock
Warranty:
1 year

Product Detail

Bently Nevada 3300 XL 11 mm Proximity Probes 330703-000-040-10-02-05
Description:
330703-000-040-10-02-05 is belong to Bently Nevada 3300 XL 11 mm Proximity Transducer System. 330703-000-040-10-02-05 is M14 x 1.5 thread, without armor, total 1m cable length, Miniature coaxial ClickLoc connector, standard cable.
The 3300 XL 11 mm probe comes in varying probe case configurations, including armored and unarmored ½-20, 5⁄8 -18, M14 X 1.5 and M16 X 1.5 probe threads. The reverse mount 3300 XL 11 mm probe comes standard with either 3⁄8-24 or M10 X 1 threads. All components of the transducer system have gold-plated brass ClickLoc connectors. ClickLoc connectors lock into place, preventing the connection from becoming loose. The patented TipLoc molding method provides a robust bond between the probe tip and the probe body. The probe cable is securely attached to the probe tip utilizing our patented CableLoc design that provides 330 N (75 lb) pull strength.

Ordering Information:
330703-AAA-BBB-CC-DD-EE
A:Unthreaded Length Option
Order in increments of 2 mm.
Length configuration:
Maximum unthreaded length: 224 mm
Minimum unthreaded length: 0 mm
B: Overall Case Length Option
Order in increments of 2 mm.
Metric thread configurations:
Maximum length:250 mm
Minimum length:26 mm
C: Total Length Option
10 1.0 meter (3.3 feet)
50 5.0 meters (16.4 feet)
90 9.0 meters (29.5 feet)
D: Connector and Cable-Type Option
01 Miniature coaxial ClickLoc connector with connector protector, standard cable
02 Miniature coaxial ClickLoc connector, standard cable
11 Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable
12 Miniature coaxial ClickLoc connector, FluidLoc cable
E: Agency Approval Option
00 Not required
05 Multiple Approvals
