330195-02-12-05-00 Bently Nevada Extended Temperature Range (ETR) Reverse Mount Probes

Bently Nevada 3300 XL 8 mm Extended Temperature Range (ETR) Reverse Mount Probes 330195-02-12-05-00

Brand:
Bently Nevada TSI
Item NO.:
330195-02-12-05-00
Order(MOQ):
1 PC
Payment:
T/T
Product Origin:
USA
Shipping Port:
Xiamen
Lead Time：
In stock
Warranty:
1 year

Product Detail

Bently Nevada 330195-02-12-05-00 3300 XL 8 mm Extended Temperature Range (ETR) Reverse Mount Probes
Description:
330195-02-12-05-00 is belong to Bently Nevada 330195-02-12-05-00 Probe.
330195-02-12-05-00 is a Reverse Mount Probe, 3/8-24 UNF threads , total 0.5 m cable length.
An extended temperature range (ETR) probe and ETR extension cable are available for applications in which either the probe lead or extension cable may exceed the standard 177 ˚C (350 ˚F) temperature specification. The ETR
probe has an extended temperature rating for up to 218 ˚C (425 ˚F). The ETR extension cable rating is up to 260 ˚C (500 ˚F). Both the ETR probe and cable are compatible with standard temperature probes and cables, for example,
you can utilize an ETR probe with the 330130 extension cable. The ETR system uses the standard 3300 XL Proximitor Sensor. Note that when you use any ETR component as part of your system, the ETR component limits the system accuracy to the accuracy of the ETR system.

Ordering Information:
30195-02-12-CC-DD
C: Total Length Option
05 0.5 meter (1.6 feet)
10 1.0 meter (3.3 feet)
15 1.5 meter (4.9 feet)
20 2.0 meters (6.6 feet)
50 5.0 meters (16.4 feet)
90 9.0 meters (29.5 feet)
D: Agency Approval Option
00 Not required
05 CSA, ATEX, IECEx approvals

FAQ:
What's the difference between 330195 and 330196?
330195 is DD3/8-24 UNF threads, 330196 M10 x 1 threads.

What is the outer jacket for ETR probes 330195?
PFA jacket on nonarmored portion for ETR probes.

What is the Extended Temperature Range (ETR) for 5 and 9 Meter Systems?
7.87 V/mm (200 mV/mil) ± 6.5% including interchangeability error when measured in increments of 0.25 mm (10 mils) over the 80 mil linear range from 0 °C to +45 °C (+32 °F to +113 °F).

Lead time: 1-2 working days.
Terms of payment:T/T and Western Union.
Courier partners: DHL, UPS, TNT, FedEx and EMS.
