Bently Nevada 330101-00-20-10-02-05 3300 XL 8 mm Proximity Probes

Bently Nevada 330101-00-20-10-02-05 3300 XL 8 mm Proximity Probes with 1 meter length cable

  • Brand:

    Bently Nevada TSI
  • Item NO.:

    330101-00-20-10-02-05
  • Order(MOQ):

    1 PC
  • Payment:

    T/T
  • Market Price:

    999
  • Price:

    $999
  • Product Origin:

    USA
  • Shipping Port:

    Xiamen
  • Lead Time:

    In stock
  • Warranty:

    1 year
Product Detail
Bently Nevada 330101-00-20-10-02-05 3300 XL 8 mm Proximity Probes
Description:

330101-00-20-10-02-05 is one of Bently Nevada 3300 XL 8 mm Proximity Probes. 330101-00-20-10-02-05 is 3/8-24 UNF thread, without armor, 1 meter total length cable with Miniature coaxial ClickLoc connector, CSA, ATEX, IECEx Approvals.

The 3300 XL probe reflects improvements over previous designs. A patented TipLoc molding method provides a more robust bond between the probe tip and the probe body. The probe’s cable incorporates a patented CableLoc design that provides 330 N (75 lbf) pull strength to more securely attach the probe cable and probe tip.

8 mm probes provide a thicker encapsulation of the probe coil in the molded PPS plastic probe tip. This results in a more rugged probe. The larger diameter of the probe body also provides a stronger, more robust case. We recommend that you use 8 mm probes when possible to provide optimal robustness against physical abuse.

3300 XL 8mm Proximity Transducer System provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.

Ordering Information:
330101-AA-BB-CC-DD-EE
A: Unthreaded Length Option
B: Overall Case Length Option
C: Total Length Option
05   0.5 meter (1.6 feet)
10   1.0 meter (3.3 feet)
15   1.5 meter (4.9 feet)
20   2.0 meters (6.6 feet)
30   3.0 meters (9.8 feet)
50   5.0 meters (16.4 feet)
90   9.0 meters (29.5 feet)
D: Connector and Cable-Type Option
01   Miniature coaxial ClickLoc connector with connector protector, standard cable
02   Miniature coaxial ClickLoc connector, standard cable
11   Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable
12   Miniature coaxial ClickLoc connector, FluidLoc cable
E: Agency Approval Option
00   Not required
05   CSA, ATEX, IECEx Approvals

330101-00-20-10-02-05

Bently Nevada 330101-00-20-10-02-05
