ABB 83SR07F-E GJR2392700R1210 Analog Control Module
Description:
83SR07F-E is one of ABB PROCONTROL P system Analog Control Module.

83SR07F-E is used for stored-program control of one or two process variables.  The module has two continuous outputs for outputting the correcting variables.  The following types of actuators (positioners, servo-drives) can be activated: - Electrohydraulic motor-driven actuators - Electropneumatic actuators - Electric-motor-driven actuators The positioning of the actuators is controlled locally, via the converter, or, in the case of the electric-motor-driven actuators, by a continuously operating power electronic system.  In addition to single-variable control, it is possible to implement a higher-level master control.

83SR07F-E is intended to be used in combination with the process operator station. The module includes the function blocks needed for implementing continuous single-variable controllers.  Other function blocks are available for signal conditioning. In analog control mode, the module is used with a fixed cycle time, i.e. 100 msec for one actuator and 200 msec for two actuators.  It is also possible to preset a cycle time of 50 msec. The cycle time is specified by means of KON function block which is the first block to be listed in the structure list.   The module incorporates two hardware process interfaces for the power controller units and for the process.
