ABB 07KT97 GJR5253000R0100 Advant Controller 31 Basic Units
ABB 07KT97 GJR5253000R0100 Advant Controller 31 Basic Units
Brand:
ABB DCSItem NO.:
ABB 07KT97Order(MOQ):
1Payment:
T/TMarket Price:
999Price Range:
1 - 5Product Origin:
GermanyColor:
Depends on materialShipping Port:
XIAMENLead Time：
IN STOCK
ABB 07KT97 GJR5253000R0100 Advant Controller 31 Basic Units
Description：
The basic unit 07 KT 97 R200 is the standard device for all applications. It works either as
· bus master in the decentralized automation system Advant Controller 31 or as
· slave (remote processor) in the decentralized automation system Advant Controller 31 or as
· stand-alone basic unit.
The basic unit is powered by 24 V DC.
|
User program |
480 kB |
|
User data |
256 kB (Flash EPROM) |
|
Digital inputs |
24 in 3 groups of 8 each, electrically isolated |
|
Digital outputs |
16 transistor outputs in 2 groups of 8 each, electrically isolated |
|
Digital inputs/outputs |
8 in 1 group, electrically isolated |
|
Analog inputs |
8 in 1 group, individually configurable to 0...10 V, 0...5 V, +10 V, +5 V, 0...20 mA, 4...20 mA, Pt100 (2-wire or 3-wire), differential inputs, digital inputs |
|
Analog outputs |
4 in 1 group, individually configurable to 0...10 V, 0...20 mA, 4...20 mA |
|
Serial interfaces |
COM1, COM 2 as MODBUS interfaces and for programming and test functions |
|
Parallel interfaces for connection of couplers |
07 KP 90 (RCOM), 07 KP 93 (2 x MODBUS), 07 MK 92 (freely programmable) |
|
High-speed counter |
integrated, many functions configurable |
|
Real-time clock |
integrated |
|
SmartMedia Card |
memory medium for operating system, user program and user data |
|
Data backup |
with lithium battery 07 LE 90 |
